Temperature Controllers
* Information in this page is a reference that you created on the basis of information in the product catalog before the end of production, may be different from the current situation, such as goods for / supported standards options / price / features of the product. Before using, please check the compatibility and safety system.
last update: June 1, 2020
Size | Type | Control
modes |
Alarms | Outputs | Model with
thermocouple |
Model with
platinum resistance thermometer |
---|---|---|---|---|---|---|
E5CSV
48 × 48mm |
Terminal
block |
ON/OFF
or PID |
1 | Relay | E5CSV-R1KJ-W | E5CSV-R1P-W |
Voltage (for driving SSR) | E5CSV-Q1KJ-W | E5CSV-Q1P-W |
Size | Type | Control modes | Alarms | Outputs | Model with thermocouple |
---|---|---|---|---|---|
E5CSV 48 × 48mm |
Terminal block | ON/OFF or PID | 1 | Relay | E5CSV-R1KJD-W |
Size | Type | Control modes | Alarms | Outputs | Model with universal-input
(thermocouple or platinum resistance thermometer) |
---|---|---|---|---|---|
E5CSV
48 × 48mm |
Terminal block | ON/OFF or PID | 0 | Relay | E5CSV-RT |
Voltage (for driving SSR) | E5CSV-QT | ||||
1 | Relay | E5CSV-R1T | |||
Voltage (for driving SSR) | E5CSV-Q1T | ||||
2
(See note.) |
Relay | E5CSV-R2T | |||
Voltage (for driving SSR) | E5CSV-Q2T |
Size | Type | Control modes | Alarms | Outputs | Model with universal-input
(thermocouple or platinum resistance thermometer) |
---|---|---|---|---|---|
E5CSV
48 × 48mm |
Terminal block | ON/OFF or PID | 0 | Relay | E5CSV-RTD |
Voltage (for driving SSR) | E5CSV-QTD | ||||
1 | Relay | E5CSV-R1TD | |||
Voltage (for driving SSR) | E5CSV-Q1TD | ||||
2
(See note.) |
Relay | E5CSV-R2TD | |||
Voltage (for driving SSR) | E5CSV-Q2TD |
Type | Model |
---|---|
Hard Protective Cover | Y92A-48B |
Model |
---|
E53-COV17 |
Note: The E53-COV10 cannot be used.
Model |
---|
Y92F-52 |
Model |
---|
Y92S-29 |
Note: The Rubber Packing is provided with the Digital Controller.
